PTBR-X Carbon Zapp — professional test bench for diagnostics and testing of diesel Common Rail and gasoline GDi high-pressure pumps.

Designed for diesel service centers and fuel system repair workshops, the bench provides precise and rapid testing of all pump types, including EU6 and Heavy-Duty systems.

PTBR-X advantages:

dedicated CR and GDi pump testing
pressure up to 2800+ bar
EU6 technology support
compatibility with all pump manufacturers
PCV, VCV and pressure sensor testing
Heavy-Duty pump diagnostics
fast testing cycles
CloudX platform

CZ_DIESEL_SPECIALIST_PTBRX

PTBR|X-Pack1 (STANDARD PACKAGE)

Exclusive Package. Includes: [(CRp -IP.3 KIT, CRP_HPOUT2)x1, VDCP.01x2]
PTBR|X-Pack_2

Exclusive Package. Includes: [(CRp-VDD, CRp-CP4.KIT, CZ-007477, CRP.DNC-HP5.KIT, CZ-007491)x1, 007156x3]
PTBR|X-Pack_3

Exclusive Specialists CRp Package Includes: [(VCV.S, CRp-VDD, CRP-CP4.KIT.01, CPN5.01-KIT, CZ-007477, CRP.DNC-HP5.KIT, CZ-007491, ZME-CPN5-01, VCVA.01, VCVA.02, VCV.D1-KIT])x1], CZ-007156x3

ΑΖΟ.GD-p

SOFTWARE UPGRADE LICENSE FOR TESTING GASOLINE GDi PUMPS
CZ-007647

IMA-QSK License for activation [REQUIRES RSP-HD & COOLING SYSTEM TBA]
CZ-007741

License activation for UHD Marine Injectors
CZ-007705

License activation for CRp L’Orange
CZ-007706

License activation for CRp CP9
CZ-007707

License activation for Pressure Sensor Element [RDS]
CZ-007708

License activation for Pressure Control Element [PCV]
CZ-007658

HP0 License for activation
CZ-007656

CRp - CAT License for activation
CZ-007492

CRP-HP6 Software for DENSO HP6 PUMPS
CZ-007650

CRP-CP4.KIT.011 License for activation
CZ-007649

CRp CP3.3/3.4 License for activation
CZ-007651

CPN5.01-KIT License for activation
CZ-007652

CPN2.01-KIT License for activation
CZ-007653

VDO EU6 Application Pumps (CZ-007477) License for activation
CZ-007654

Cummins XPi Pumps License for activation
CZ-007655

DFP8 Pumps License for activation
CZ-007657

CRp-CB18 & CRp-CB28 License for activation
CZ-007491

CRP-HP5 Software for DENSO HP5S appl. Pumps
VCV.S

CR PUMP VOLUME/METERING CONTROL VALVE MEASUREMENT SOFTWARE

CZ-002380

CARBON ZAPP BASE TROLLEY
CZ-002507

CAMBOX/PUMP TRANSFER RACK ( MAX. 2 Pcs PER TROLLEY )
CZ-002587

CRp FLANGE DRAWER ORGANIZER ( MAX. 1 Pc PER TROLLEY )
CZ-002765

HOSE & HARNESS SIDE ORGANIZER ( MAX.2 PER TROLLEY )

CZ-007357

DESK & HARNESS SELV FOR MTBRX & PTBRX
CZ-007358

HYDRAULIC HOSE SIDE PANEL WITH DRAIN FOR MTBRX & PTBRX

CRp -IP.3 KIT

COMPLETE GAUGES ASSEMBLY AND ADAPTERS KIT FOR MEASURING INTERNAL PRESSURE/VACUUM IN ALL MAKES CR PUMPS (BOSCH, DELPHI, DENSO, VDO)
CRP_HPOUT2

COMMON RAIL PUMP SECONDARY OUTPUT HP HOSE, HP FILTER AND 90DEGREES ACCUMMULATOR KIT
VDCP.01

INJECTOR CONNECTOR VDO PUMP BLUE CONNECTOR
CZ-007690

CRp-VDD ADAPTERS KIT v.3 FOR DELPHI/DENSO/VDO PUMPS
CRp CP3.3/3.4

CRp ADAPTERS KIT FOR BOSCH CP3.3 & CP3.4 PUMPS.(Requires CPL-IRK) [SW License CZ-007649 not included]
CRP-CP4.KIT.01

CRp ADAPTERS KIT FOR CP4 PUMPS ( INCLUDING EU6 ) [SW License CZ-007650 not included]
CPN5.01-KIT

CRp ADAPTERS KIT FOR CPN5S2 PUMPS [SW License CZ-007651 not included]
CPN2.01-KIT

CRp ADAPTERS KIT FOR BOSCH CPN2 PUMPS [SW License CZ-007652 not included]
CZ-007477

CRp ADAPTERS KIT V.2 FOR VDO EU6 PUMPS [SW License CZ-007653 not included]
CRP-HP5.KIT

CRp ADAPTERS KIT FOR DENSO HP5S PUMPS [SW License CZ-007491 not included]
CRP-HP6.KIT

CRp ADAPTERS KIT FOR DENSO HP6 PUMPS [SW License CZ-007492 not included]
CZ-007489

CRp ADAPTERS KIT FOR CUMMINGS XPi PUMPS ( P5594766, 4903462, 4954200, 4921431, 3973228 )[SW License CZ-007654 not included]
DFP8.01-KIT

CRp ADAPTERS KIT FOR DFP8 PUMPS [SW License CZ-007655 not included] REQUIRES 008236 FOR MTBR|X & 008172 FOR MTBR-E/D
SPR.D

ILLIMINATED PRESSURISED SPRAY CHAMBER.(REQUIRES CZ-007102)
CZ-007102

MTBr | X - MAIN LED [sh] Harness for spray tubes
ZME-CPN5-01

CABLE CONNECTOR FOR CPN5 PUMPS
EXT.80

EXTENSION INJECTOR CABLE FOR ULTRASONIC
CRp-CAT6.6

CRp ADAPTERS KIT FOR CATERPILLAR PUMPS [SW License CZ-007656 not included]
CRp-CB18

CRp ADAPTERS FOR BOSCH CB18 PUMPS (Requires CPL-IRK ) [SW License CZ-007657 not included]
CRp-CB28

CRp ADAPTERS FOR BOSCH CB28 PUMPS (Requires CPL-IRK ) [SW License CZ-007657 not included]
CZ-007424

CRp ADAPTERS KIT FOR DENSO HP0 PUMPS FOR MTBR|X / PTBR|X [SW License CZ-007658 not included]
CPL-IRK

CRp-CPL- INTERNAL RETROFIT KIT. OIL SUPPLY & CONTROL. INTERNAL UPGRADE LUBRICATION SYSTEM FOR CP PUMPS
CZ-007695

CRP ADAPTERS KIT FOR CP9L2 PUMP [SW License CZ-007706 not included]
CZ-007696

CRP ADAPTERS KIT FOR L'ORANGE PUMPS [SW License CZ-007705 not included]
VCVA.01

VOLUME CONTROL VALVE ADAPTER FOR BOSCH CP4 PUMPS [REQUIRES TO BE ORDERED WITH VCV.S]
VCV.D1-KIT

VOLUME CONTROL VALVE ADAPTERS KIT FOR DENSO HP3/4 PUMPS [REQUIRES TO BE ORDERED WITH VCV.S]
CZ-007156

CRp EU6 SYNCHRONIZATION CABLE FOR MTBr|X

D20L-ISO

CALIBRATION OIL ISO4113 FOR ALL DIESEL COMMON RAIL BENCHES w/ ELECTRONIC MEASUREMENT & TESTING UP TO 2800BAR
Y4L

ULTRASONIC CLEANING SOLVENT [4LT]
Y25L

ULTRASONIC CLEANING SOLVENT[25LT]

UB-15S

HEAT CONTROL/ 42KHZ / 1.75L [FOR R & X UNITS REQUIRES EXT.50]
UB-15E/110V

SWEEP TECHNOLOGY 31-42KHZ/DEGAS/HEAT/1.5L/ 51x137x100mm-110V (ELMA) [FOR R & X UNITS REQUIRES EXT.50]
UB-15E/220V

SWEEP TECHNOLOGY 31-42KHZ/DEGAS/HEAT/1.5L/ 51x137x100mm-220V (ELMA) [FOR R & X UNITS REQUIRES EXT.50]
UB-30E

ULTRASONIC BATH STANDARD: HEAT CONTROL/ 2,75L/ 240x137x100mm (ELMA) [WITHOUT COVER & BASKET]
UB-60E

ULTRASONIC BATH STANDARD: HEAT CONTROL/ 5,75L/ 300x151x150mm (ELMA) [WITHOUT COVER & BASKET]
UB-120E

ULTRASONIC BATH STANDARD: HEAT CONTROL/12,75L/ 300x240x200mm (ELMA) [INCLUDED COVER & BASKET]
UB-120

ULTRASONIC BATH STANDARD: HEAT CONTROL/12,75L/ 300x240x200mm (ELMA) [WITHOUT COVER & BASKET]
UB-450E

HEAT CONTROL/ 45L/ 500x300x300mm (ELMA) [WITHOUT COVER & BASKET]

Product Overview

PTBR-X Carbon Zapp — professional test bench for diesel and gasoline high-pressure pump testing

PTBR-X Carbon Zapp is a professional test bench for diagnostics and testing of diesel Common Rail and gasoline GDi high-pressure pumps used in modern fuel injection systems. The bench is designed for diesel service centers, fuel system repair workshops and remanufacturing facilities that require highly accurate, stable and fast testing of all pump types.

PTBR-X integrates diesel and gasoline pump testing in one platform and supports the key injection technologies Common Rail and Gasoline Direct Injection. This enables a complete high-pressure pump diagnostic workflow on a single piece of equipment without the need for additional benches.

Comprehensive EU6 and Heavy-Duty pump testing

The PTBR-X bench provides precise and repeatable testing of high-pressure pumps at working pressures up to 2800+ bar and supports modern EU6 standards, including passenger, commercial and heavy-duty diesel systems.

The bench allows testing of:

Common Rail pumps (CR)
gasoline GDi pumps
EU6 generation pumps (Bosch CP4, Denso HP5/HP6/HP7, VDO)
Heavy-Duty pumps (Cummins, CAT, CPN and others)
pressure control valves (PCV)
volume control valves (VCV)
rail pressure sensors (RDS)
high-pressure fuel rails

PTBR-X is fully compatible with pumps from Bosch, Denso, Delphi, Continental/VDO and other manufacturers, ensuring universal application in diesel service and fuel system repair.

CloudX — digital bench management platform

PTBR-X is equipped with the Carbon Zapp CloudX cloud platform, providing digital control and remote diagnostics of the equipment.

CloudX provides:

remote bench access
online test database updates
test reports and protocols
remote technical support
multi-bench management
service notifications

CloudX improves equipment efficiency and meets the requirements of digital diesel service and Industry 4.0.

AutoModern is the official Carbon Zapp distributor and technology bridge to the manufacturer in the diesel service market. The company provides original equipment supply, implementation of Carbon Zapp solutions, specialist training and professional technical support throughout the entire lifecycle of the test benches.

Cooperation with AutoModern guarantees equipment authenticity, access to manufacturer updates and qualified support for diesel service centers and fuel system remanufacturing facilities.
